腾达试验仪器厂：

　　一、轮廓标耐密封测量装置适用范围：

　　本产品用于用于轮廓标密封性能测试。适用于我国公路、桥梁及隧道、城市道路、其他道路或停车场等设置的轮廓标的耐密封性测试。满足规范GB/T 24970-2010轮廓标。

　　First,the outline of the standard seal resistant measuring device:

　　This product is used for contour marking sealing performance testing.It is suitable for the sealing resistance test of the outlines of roads,bridges and tunnels,urban roads,other roads or parking lots in China.Meet the specification GB/T 24970-2010 outline.

　　二、轮廓标耐密封测量装置技术参数：

　　★温度范围：A浴0～50 B浴室温～80

　　★温度波动度：±0.5

　　★温度均匀度：±0.1

　　★水泵流量：8L/min

　　★不锈钢内胆，喷塑钢板外壳、数字显示精度高

　　★加热装置采用封闭式加热器，热能损耗小

　　★加热功率：1000W

　　★内置隐藏式盘管，制冷效果快

　　★工作室尺寸：150×200×200MM×2个

　　Second,the outline standard seal resistance measuring device technical parameters:

　　★Temperature range:A bath 0~50 B bath Room temperature~80

　　★Temperature fluctuation:±0.5

　　★Temperature uniformity:±0.1

　　★Water pump flow:8L/min

　　★Stainless steel inner liner,sprayed steel plate shell,high digital display accuracy

　　★The heating device uses a closed heater,which has low heat loss.

　　★Heating power:1000W

　　★Built-in hidden coil,fast cooling effect

　　★Studio size:150×200×200MM×2

　　三、轮廓标耐密封测量装置特点及功能：

　　★产品使用静电喷塑外壳，优质不锈钢板内胆，超细玻璃纤维保温材料。采用两个水箱控制，同时高低温试验，满足轮廓标的快速、科学、准确的测试。低温水箱温度为0～50℃高温水箱温度为5～80℃

　　★控制部分采用微电脑控制，数字显示精度高，整个操作通过人机对话即可。触摸软键可快速设定温度,操作方便。微机修正温度测量值偏差，数显精度0.1℃。

　　★仪器内部采用独特的不锈钢循环水泵，强迫水循环，温度均匀，并且槽内冷液可外引,冷却机外实验容器，实现第二恒温试验。

　　★风冷式全封闭品牌压缩机组制冷。声音小，制冷快。

　　Third,the contour mark resistant seal measuring device features and functions:

　　★The product uses electrostatic spray plastic shell,high quality stainless steel inner liner,ultra-fine glass fiber insulation material.It adopts two water tank control and high and low temperature test to meet the fast,scientific and accurate test of the contour mark.The temperature of the low temperature water tank is 0~50°C,and the temperature of the high temperature water tank is 5~80°C.

　　★The control part adopts microcomputer control,the digital display has high precision,and the whole operation can be through human-machine dialogue.Touch the soft key to quickly set the temperature for easy operation.The microcomputer corrects the deviation of the temperature measurement value,and the digital display accuracy is 0.1°C.

　　★The instrument uses a unique stainless steel circulating water pump to force the water circulation,the temperature is even,and the cold liquid in the tank can be externally led to cool the experimental container outside the machine to achieve the second constant temperature test.

　　★Air-cooled fully enclosed brand compressor unit refrigeration.The sound is small and the cooling is fast.

　　四、轮廓标耐密封测量装置设备使用条件：

　　★环境温度：5～35（24小时内平均温度28）

　　★环境湿度：85%

　　Fourth,the outline standard seal-resistant measuring device equipment conditions:

　　★Ambient temperature:5~35(average temperature of 24 hours within 24 hours)

　　★Environmental humidity:85%
